How to Livestream a DJ Set With OBS: Clean Mixer Audio, 48 kHz and Video That Stays in Sync

You have the mixer, the laptop and a decent webcam. You open OBS, hit Start Streaming, and the chat tells you the audio is crackling, the volume is tiny, or your hands on the jog wheel are half a second behind the kick. Or worse, there is no sound at all and you only find out after twenty minutes.

Most guides on how to livestream a DJ set with OBS were written for gamers or for a 2020 lockdown setup, and they skip the parts that actually break for DJs: getting a clean stereo feed from a mixer, matching sample rates, and keeping the picture in sync with the music. This guide covers the setup that works in 2026, step by step, with the settings worth changing and the ones to leave alone. It is about the technical side; music rights on each platform are a separate question you should check before you go live.

What do you need to livestream a DJ set with OBS?

You need four things: your DJ setup, a way to get its master output into the computer as a clean digital signal, a camera, and OBS Studio, which is free and runs on macOS, Windows and Linux. Everything else is optional.

• Audio path: either the built-in USB audio of your mixer or controller, a separate audio interface fed from the mixer's record or booth output, or a virtual audio cable if you DJ entirely in software on the same computer.
• Camera: a recent webcam is fine to start. A mirrorless camera with clean HDMI out and a capture card looks noticeably better in low light.
• Light: one soft light in front of you and one coloured light behind does more for the picture than a better camera.
• Connection: a wired ethernet connection. Wi-Fi drops are the most common reason a stream dies mid-set.

How to get clean audio from your DJ mixer into OBS

Never use the laptop's built-in microphone or line input for the music. Capture the master digitally, before any room sound gets near it.

If your mixer or controller has a built-in sound card with a record output over USB, this is the cleanest route. Connect it, then in OBS add a source called Audio Input Capture, select the mixer's USB device, and name it something obvious such as Decks. In OBS's audio settings, disable the default Desktop Audio and Mic sources so nothing else leaks into the stream.

If your mixer has no USB audio, take its record output or a spare booth output into a simple two-channel audio interface, and capture that interface in OBS the same way. Record outputs are usually unaffected by the master volume knob, which means you can turn the speakers down at home without changing the stream level.

If you DJ entirely inside software on the same machine, route the software's output to a virtual audio device. On macOS the common free option is BlackHole; on Windows it is VB-Audio Virtual Cable. Set your DJ software's master output to that device, then add the device as an Audio Input Capture in OBS. On a Mac you can build a Multi-Output Device in Audio MIDI Setup so you hear the mix in your headphones or speakers at the same time.

Which OBS audio settings matter for a DJ stream?

Three settings cause most of the problems DJs hit, and they are all quick to fix.

• Sample rate. Set OBS to 48 kHz in Settings, Audio, and set your interface or mixer's USB audio to the same 48 kHz in your operating system. A mismatch is the classic cause of crackling and of audio that slowly drifts out of sync over a long set.
• Audio bitrate. In Settings, Output, set the audio track to 160 kbps AAC for Twitch, which is the commonly recommended figure there. For a music-first stream on a platform that accepts more, a higher bitrate is worth testing, but never at the cost of dropped frames.
• Levels. Aim for your Decks meter in OBS to peak in the yellow, around minus 10 to minus 6 dBFS, and never touch the red. Set gain on the mixer, not with the OBS fader, and add a limiter filter on the Decks source with the ceiling just below 0 dB as a safety net, not as a loudness tool.

Turn off any noise suppression or noise gate on the music source. Those filters are designed for voices and will chew up hi-hats and reverb tails. If you want to talk between tracks, use a separate microphone source with its own gate, and keep it muted while you mix.

How do you stop the video and audio drifting out of sync?

Webcams and capture cards add delay to the picture, so the sound often arrives before your hand hits the fader. Fix it per source in OBS: right-click the Decks audio source, open Advanced Audio Properties, and add a Sync Offset in milliseconds. A positive value delays the audio to match the late video.

Test it with a clap or a hard cue. Hit play on a track with a sharp transient while clapping on the beat in view of the camera, record ten seconds locally, and watch it back frame by frame. Adjust in steps of 20 to 50 milliseconds until the clap and the kick land together. Capture cards often need more delay than a USB webcam, so measure your own chain instead of copying someone else's number.

If the sync is fine at the start but drifts over an hour, go back to the sample rate check. Drift is nearly always a rate mismatch rather than a delay problem.

Best OBS video settings for a DJ stream

For most home connections, 1080p at 30 frames per second is the sweet spot for a DJ stream. Hands on a mixer do not need 60 frames, and the bandwidth you save goes into a cleaner picture. On Twitch, 6000 kbps is the figure most guides give as the top end for 1080p, and a 720p stream at around 3000 kbps is a safe fallback on weaker upload speeds.

Use a hardware encoder if your machine has one, such as NVENC on recent Nvidia cards or the Apple VT hardware encoder on Apple silicon Macs. That keeps the processor free for your DJ software, which matters because an overloaded CPU is the fastest way to get audio dropouts in the mix itself.

Build two or three scenes and switch between them during long blends rather than cutting constantly:

• Wide shot: you, the decks and the room or backdrop.
• Overhead or decks close-up: hands on the mixer. Viewers who DJ love this angle.
• Holding scene: your logo or the flyer with the audio still running, for the moment you need to fix something.

Test before you go live

Every stream problem is easier to find in a test than in front of an audience. Before the real stream, record a 15 minute local test in OBS using the exact settings you will stream with, then play it back on headphones and on a phone speaker. Check the level, the sync at the start and at the end, and whether anything else on the computer, such as a notification sound, leaked into the mix.

Then run a short unlisted or private test stream on the platform you plan to use. Watch the stats panel in OBS for dropped frames; if the number keeps climbing, lower the video bitrate before you lower anything else.

Finally, record locally while you stream. OBS can do both at once. If the stream fails or gets muted, you still have a clean copy of the set for YouTube, SoundCloud or your own archive.

What to do this week

Install OBS, set everything to 48 kHz, and add your mixer as a single Audio Input Capture called Decks. Record a 15 minute test with a clap at the start and the end and fix the sync offset. Build three scenes. Then book a date for a short public stream, an hour at most, and tell your audience in advance. A tidy, well-synced hour beats a four hour stream that sounds like it was recorded through a wall.
